升降平臺-HT
◆重型設計,品牌高質量泵站,貨物提升平穩有力
◆臺面下方四周安全檔條裝置,當臺面下降遇到遇到障礙物時立即停止,確保安全
◆采用防夾剪叉設計,防止夾傷,帶過載保護功能,更安全、可靠
◆液壓系統配備有防爆閥,當油管爆裂時,可防止平臺急速下降
◆可拆卸吊環,方便平臺運輸和安裝
◆高提升作業,廣泛適用于倉儲、物流、制造、維修等場合
◆符合 EN1570 和 ANSI/ASME安全標準
● Heavy duty design and can be used in above-floor or in-floor pit applications.
● High quality power unit for stable and safe lifting.
● Upper platform lifted with aluminum safety bar preveting descent on contact with obstructions.
● Safety
clearance between scissors to prevent trapping and equipped with
overload protection system to ensure your safe operation.
● Removable lifting eye to facilitable handling and lift table installation
● The products are widely used in warehousing operation,logistics base, manufacturing and maintenance industries
● Meet EN1570 norm and ANSI/ASME safety standard.
| 型號Model | HT1000 | HT2000 |
| 頦定載重Capacity (kg) | 1000 | 2000 |
| 臺面尺寸Platform Size (mm) | 1700×1000 | 1700×1000 |
| 底座尺寸Base Frame Size (mm) | 1600×1000 | 1606×1010 |
| 臺面最低高度Lowered Height (mm) | 470 | 560 |
| 臺面最高高度Raised Height (mm) | 3000 | 3000 |
| 起升時間Lift Time (s) | 35-45 | 50-60 |
| 泵站參數Power Pack | 380V/50HZ AC 2.2Kw | |
| 凈重Net Weight (kg) | 450 | 750 |
